M-Color Single User License US $565.25 M-Color Network License US $802.75 M-Color Professional Color Plotting M-color is a professional color plotting program for AutoCAD users. It improves the quality and appearance of AutoCAD designs. You can apply graphic effects to whole AutoCAD layers and save color configurations for re-use with other drawings – an essential feature for productive CAD work. M-Color lets you improve the appearance of your plots in many...

EZ-Duct HVAC 2D/3D Bundle Sq./Rect./Round US $495.00   Use Coupon Code: X10SUB31OC07 for $100.00 OFF EZ-Duct™ is a quick input parametric 2D/3D drafting program for the creation of square and rectangular duct and fittings, designed especially for contractors. Draws flexible duct run-outs to registers. HVAC system layering controlled by groups. Automatic cut tickets for each HVAC system fitting, with quantities. Annotation automatically added as fitting are...

When it comes to piping our name says it all! EZ-Pipe Plus is a parametrically driven piping system that makes piping drawings a matter of completion. Combined with a Bill of materials, for total pipe length or individual cut pipe length, this makes EZ-Pipe a winning combination. EZ-Pip Plus also contains several drawing enhancements including a layer management system to manage layers by groups. Don’t take our word for it, take theirs…. “The...

Welding Symbols for AutoCAD US $99.00 Welding Symbols has a new user interface. Now you can create the entire welding symbol before placing it on your drawing. Each specific symbol may be saved for reuse, at the touch of a button, over and over, revising the previous symbol to create new ones.  Welding Symbols are based on ANSI/AWS specifications and give you complete control over every aspect of each symbol. The preferences dialog allows you to specific the...

Steel Floor and Roof Deck For AutoCAD US $99.00 As fast as selecting two points your deck is created as a single polyline based on the type selected. It’s that quick and that simple, just select the type of deck from the dialog click OK and then select two points, instant deck!  Create Steel Deck in AutoCAD 2D for details or 3D for presentations. Steel Floor Deck creates narrow, intermediate and wide rib roof deck with your choice of insulation type and...

Open Web Steel Joist for AutoCAD US $99.00 Draw a bar joist in 2D/3D elevation or section in seconds, not the usual 15 or 20 minutes for 2D or who knows how long for 3D. Bar joists are created as a 3D Solid simply by selecting an existing line representing the bar joist length and 3D placement within seconds.  No data manuals to find and look up the dimensional information you need to draw a steel bar joist in AutoCAD. Create joists in 2D for details or 3D for...

Bolts Nuts Washers For AutoCAD US $99.00   Bolts/Nuts/Washers parametrically creates these shapes in plan or elevation views based on dimensional data from external ASCII data files. You may add additional dimensional information on bolts or nuts that are unique to your specific application. Bolts drawn in elevation allow for a material thickness to be specified, using hidden lines to represent the shaft through the material. A washer may be added at the bolt head...

Upgrade Structural Steel Shapes US $149.00 Structural Steel Shapes US $195.00 Structural Steel Detailing For AutoCAD SteelPLUS™ Structural Shapes includes W-Shapes, channels, single/double angles, square & rectangular tubing, pipes, M, S, HP shapes and tees as listed in the AISC database. Optional metric databases included MAISC and CISC. All structural steel shapes are parametrically drawn according to the “Manual of Steel Construction”  of the...
